76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA

I'm Online Chat Now

76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA

76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA
76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA 76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA 76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA 76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA 76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA 76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA

Large Image :  76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA

Product Details:
Place of Origin: China
Brand Name: SUNFiD
Certification: CE,FCC,MSDS,ROHS,UN38.3
Model Number: OKUPS600VA
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Packaging Details: Hard Paper Carton with Foam From Top and Button
Delivery Time: 10-30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30000 pcs per month

76.8Wh Lithium Iron Phosphate Battery UPS Offline 600VA

Description
Color: Black Warrenty: 12 Months
Charge Period: 8 Hours To Be Full Chargecurrent: 1A
Input Voltage: 110v/220v Display: LED/LCD Optional
High Light:

76.8Wh lithium iron phosphate battery ups

,

lithium iron phosphate battery ups Offline

,

600VA li ion ups

UPS Lithium Battery UPS Manufacturer OEM Lithium Iron Phosphate Battery 76.8Wh Offline UPS 600VA



Overview
Quick Details
Warranty:  1year
Place of Origin:  Guangdong, China
Brand Name:  OKTANMAX
Model Number:  OKUPS600VA
Phase:  Single Phase
Protection:  Overvoltage
Weight:  3.7kg
Type:  STANDBY
Application:  COMPUTER
Product name:  Lithium UPS 600va
transfer time:  4-8ms
Wave Form:  Modified Sine Wave
Capacity:  60% of rated power
Display:  LED/LCD optional
Input voltage:  110v/220v
chargecurrent:  1A
charge period:  8 hours to be full
warrenty:  12 months
Color:  Black

Supply Ability
100000 Unit/Units per Month
Packaging & Delivery
Packaging Details
1. Inner: color box;
2. Outer: Standard export carton;
3. Customized package.
Port:  Shenzhen

ead Time:

Quantity(Sets) 1 - 100 101 - 1000 >1000
Est. Time(days) 16 20 To be negotiated



MODEL OKUPS600VA OKUPS1000VA OKUPS1200VA
CAPACITY 600VA/360W 1000VA/500W 1200VA/720W
INPUT
Voltage 220VAC
Voltage Range 162-268Vac
Frequency Range 50Hz±1Hz or 60Hz±1Hz (auto sensing)
OUTPUT

Voltage Regulation

(Batt. Mode)

220VAC ±10%

Frequency Range

(Batt. Mode)

50Hz±1Hz or 60Hz±1Hz (auto sensing)
Transfer Time Typical 4-8ms, 13ms max
Waveform (AC. Mode) sine wave
Waveform (Batt. Mode) Simulated Sine Wave
BATTERY
Battery Voltage 12.8V

Battery capacity

(Lithium iron

phosphate battery)

76.8Wh 70.4Wh 153.8Wh
Backup time 100w load ≈ 30 minutes 100w load ≈ 27 minutes 200w load ≈ 30 minutes
Maximum Charge Current ≈ 1.0 A
PROTECTION
Full Protection short circuit, Overload , Overcharge and overdischarge protection
ALARM
Battery mode Sounding every 10 seconds
Low Battery Sounding every second
Overload Sounding every 0.5 seconds
Fault Continuously sounding
PHYSICAL

Approx. Dimension

D*W*H (mm)

306X86X140
OPERATING ENVIRONMENT
Humidity 0-90 % RH @ 0- 40°C (non-condensing)
Noise Level Less than 40dB( 1 m spacing)
MANAGEMENT
Communication port For choice(USB&RJ45&USB charge)



Our Services
1. OEM&ODM services acceptable.
2. Lots of cooperated agent for shipping by sea or by air.
3. 1year warrenty , if it is quality problem , we will provide the parts for free .

Little hint:
1.In the warranty period the machine has a problem, please contact the sales staff, we will be responsible for customer service.
2.Exceed the warranty period, improper operation and man-made damage, we will still give help and support,We will provide spare parts at a cost price.
3.According to the customer's needs, we can provide unconventional, but the cost may be slightly higher than the traditional machine.



FAQ
Q1: Why you should choose us?
---16 years UPS experiences
---Professional team for both oversea and domestic market
--UPS provider of SCO meeting 2015 and Shanghai-Kunming high-speed railway project
---Qualified product plus competitable prices
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 12-24 months warranty since the delivery date and free maintenance /
replacement during warranty period.
Q3: What kind of certification you have?
---ISO9000, CE,ROHS,and so on
Our products could pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days; customized products could be
developed within 10-30days.
