Product Details:
|
| Color: | Black | Warrenty: | 12 Months |
|---|---|---|---|
| Charge Period: | 8 Hours To Be Full | Chargecurrent: | 1A |
| Input Voltage: | 110v/220v | Display: | LED/LCD Optional |
| High Light: | 76.8Wh lithium iron phosphate battery ups,lithium iron phosphate battery ups Offline,600VA li ion ups |
||
UPS Lithium Battery UPS Manufacturer OEM Lithium Iron Phosphate Battery 76.8Wh Offline UPS 600VA
Overview
Quick Details
Warranty: 1year
Place of Origin: Guangdong, China
Brand Name: OKTANMAX
Model Number: OKUPS600VA
Phase: Single Phase
Protection: Overvoltage
Weight: 3.7kg
Type: STANDBY
Application: COMPUTER
Product name: Lithium UPS 600va
transfer time: 4-8ms
Wave Form: Modified Sine Wave
Capacity: 60% of rated power
Display: LED/LCD optional
Input voltage: 110v/220v
chargecurrent: 1A
charge period: 8 hours to be full
warrenty: 12 months
Color: Black
Supply Ability
100000 Unit/Units per Month
Packaging & Delivery
Packaging Details
1. Inner: color box;
2. Outer: Standard export carton;
3. Customized package.
Port: Shenzhen
ead Time:
| Quantity(Sets) | 1 - 100 | 101 - 1000 | >1000 |
| Est. Time(days) | 16 | 20 | To be negotiated |
| MODEL | OKUPS600VA | OKUPS1000VA | OKUPS1200VA |
| CAPACITY | 600VA/360W | 1000VA/500W | 1200VA/720W |
| INPUT | |||
| Voltage | 220VAC | ||
| Voltage Range | 162-268Vac | ||
| Frequency Range | 50Hz±1Hz or 60Hz±1Hz (auto sensing) | ||
| OUTPUT | |||
|
Voltage Regulation (Batt. Mode) |
220VAC ±10% | ||
|
Frequency Range (Batt. Mode) |
50Hz±1Hz or 60Hz±1Hz (auto sensing) | ||
| Transfer Time | Typical 4-8ms, 13ms max | ||
| Waveform (AC. Mode) | sine wave | ||
| Waveform (Batt. Mode) | Simulated Sine Wave | ||
| BATTERY | |||
| Battery Voltage | 12.8V | ||
|
Battery capacity (Lithium iron phosphate battery) |
76.8Wh | 70.4Wh | 153.8Wh |
| Backup time | 100w load ≈ 30 minutes | 100w load ≈ 27 minutes | 200w load ≈ 30 minutes |
| Maximum Charge Current | ≈ 1.0 A | ||
| PROTECTION | |||
| Full Protection | short circuit, Overload , Overcharge and overdischarge protection | ||
| ALARM | |||
| Battery mode | Sounding every 10 seconds | ||
| Low Battery | Sounding every second | ||
| Overload | Sounding every 0.5 seconds | ||
| Fault | Continuously sounding | ||
| PHYSICAL | |||
|
Approx. Dimension D*W*H (mm) |
306X86X140 | ||
| OPERATING ENVIRONMENT | |||
| Humidity | 0-90 % RH @ 0- 40°C (non-condensing) | ||
| Noise Level | Less than 40dB( 1 m spacing) | ||
| MANAGEMENT | |||
| Communication port | For choice(USB&RJ45&USB charge) | ||
Our Services
1. OEM&ODM services acceptable.
2. Lots of cooperated agent for shipping by sea or by air.
3. 1year warrenty , if it is quality problem , we will provide the parts for free .
Little hint:
1.In the warranty period the machine has a problem, please contact the sales staff, we will be responsible for customer service.
2.Exceed the warranty period, improper operation and man-made damage, we will still give help and support,We will provide spare parts at a cost price.
3.According to the customer's needs, we can provide unconventional, but the cost may be slightly higher than the traditional machine.
FAQ
Q1: Why you should choose us?
---16 years UPS experiences
---Professional team for both oversea and domestic market
--UPS provider of SCO meeting 2015 and Shanghai-Kunming high-speed railway project
---Qualified product plus competitable prices
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 12-24 months warranty since the delivery date and free maintenance /
replacement during warranty period.
Q3: What kind of certification you have?
---ISO9000, CE,ROHS,and so on
Our products could pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days; customized products could be
developed within 10-30days.
