Product Details:
|
| Item Name: | 8KW DC To AC Power Inverter | Type: | DC/AC Inverters |
|---|---|---|---|
| Output Type: | Single, Single/Split Phase | Output Current:: | Load |
| Size:: | 550*255*630mm | Output Waveform:: | Pure Sine Wave |
| Peak Power: | 3 Times Of Rating Power | ||
| High Light: | 8000W Pure Sine Wave Power Inverter,220V Pure Sine Wave Power Inverter,8KW inverter dc to ac pure sine wave |
||
Pure Sine Wave Power Inverter 8000W 220VAC Low Frequency With AC Charger Power Inverter
Product Description:
1. Pure sine wave output,available for sensitive load.
2. 3-step progressive charging,7 battery type selector.
3. 35A/50A/70A/90A(According to the inverter model).
4. High power factor.
5. Automatically transfer between battery and line modes.
Product Applications:
All kinds of home appliances,office equipment,solar power system,and other equipment which use single phase power.
Parameters:
| Model | PW8000W | |
| AC Input | Nominal Power | 8000W |
| Input Voltage Waveform | Sinusoidal | |
| Nminal Iput Voltage | 230VAC | |
| Low line Disconnect | 184VAC±4%(Normal) or 135VAC±4%(Wide) | |
| High Line Disconnect | 263VAC±4%(Normal) or 263VAC±4%(Wide) | |
| AC Output | Output Voltage | 230VAC±10% |
| Output Frequency | 60Hz±0.3Hz/ 50Hz±0.3Hz | |
| Solar Charger | Rated Charge Current | 60A |
| Max.PV Open Circuit Array Voltage | 110VDC | |
| Charger Mode | MPPT | |
| AC Charger | Charger Current | 35A |
| System | Protection | Low battery, over charging,over load,over temp |
| Dimension | 538*255*630mm | |
| Weight | 60.1KG | |
FAQ:
Q1. What's the terms of payment?
A. We accept TT,30% deposit and 70% balance before shipment
Q2. How's the delivery time?
A. usually it will take about 3-5 working days for sample and 10-15 working days for bulk production
Q 3. What kind of material of transformer?
A. 100% copper which has a long service life and higher efficiency.
Q4. Would you accept to use our logo?
A. We would provide free OEM order depends on your quantity.
