Product Details:
|
| Model: | OK-BOX6 | Product Name: | 5kwh Powerwall For Solar Energy Storage System |
|---|---|---|---|
| Battery: | 51.2V 96Ah LiFePO4 Battery | Cycle Life: | 3000 Times At 100%DODA |
| Charge & Discharge Current: | 100A | Dimension: | 480*170*650mm |
| High Light: | ESS lithium ion battery powerwall,Solar lithium ion battery powerwall,5kwh lithium power wall |
||
Powerwall Lithium Battery Solar ESS lithium ion battery 5kwh 51.2V 48V LiFePO4 power wall battery
Specifications:
| Model | OK-BOX6 |
| Battery Type | LiFePO4 |
| Energy | 4.9KWh |
| Rated Capacity | 96Ah |
| Rated Voltage | 51.2 Volt |
| Battery cell | Square / Cube / Prismatic / Prismary / Pouch 3.2V 96Ah 100AH 102Ah 105Ah Li ion battery LiFePO4 Lithium iron phosphate battery |
| Configuration (*S*P) | 16S1P |
| Disharge Cut-off Protect Voltage | 40V |
| Charge Cut-off Protect Voltage | 58.4V |
| Max. Charge Current | 100A |
| Max. Discharge Current | 100A |
| Communication Port | CAN, RS485, RS232 |
| Compitable Inverter Brand | DEYE, Luxpower, Megarevo, SMA, Growatt, Solax, Solis,Sungrow, Sofar, Voltronic, Goodwe, Must off-grid or hybrid inverter etc. |
| Parallel | Max. 15 units in Parallels to get 74kwh. |
| Cycle life | 6000-8000 times |
| L*W*H (mm) | 480*170*650mm |
| Net Weight (KG) | 50KG |
| Cooling | Natural cooling |
| Environment | Indoor |
| Mounting options | Wall mount |
| Discharge Temperature (℃) | -10℃~+60℃ |
| Charge Temperature (℃) | 0℃ ~+45℃ |
| Storage Conditions |
–20°C to 30°C (–4°F to 86°F) Up to 95% RH, non-condensing State of Energy (SoE): 25% initial |
| Maximum Elevation | 3000 m (9843 ft) |
What is a solar battery and how does it work?
Solar panels make more electricity during the middle of the day than they do at any other time.
The middle of the day also happens to be when homes use the least amount of electricity. Because of this, your solar panels will produce a lot of electricity in the afternoon that you won’t need.
Solar batteries are able to store that extra solar energy so you can use it later on.
Solar powerwall batteries are able to store that extra solar energy so you can use it later on. This lets you power your home on clean renewable energy from your solar panels, even when they aren’t producing electricity.
What’s great about installing a solar powerwall battery is that it allows you to be less reliant on the grid while ensuring you have access to reliable backup power when there’s a power outage.
