Product Details:
|
| Material: | Aluminium Casting | Product Name: | 2200W Battery Chaeger |
|---|---|---|---|
| AC Input Operation Voltage Range: | 85V-265V | Output Power: | 2200W |
| Protection Level: | IP66 | Overall Size: | 282*124*72mm |
| Highlight: | 25A 60v 30ah lithium battery charger,72V 60v 30ah lithium battery charger,100Ah lithium 36v battery charger |
||
Lithium Battery Charger 100Ah 150Ah 200Ah 96V 15A 18A 84V 20A 72V 25A 60V 30A 48V 35A 36V 24V 12V 40A LiFePO4 Battery
Specifications:
| Model: | OK-CH-2200 | Max Power: | 2200W |
| Shell: | Aluminium casting | DC Output | Customizable |
| AC Input: | 85V-265V/40-70Hz | Waterproof: | IP66 |
| Max Efficiency: | >=93% | Operating Temperature: | -30 to 65℃ |
| Storage Temperature: | -40 to 95℃ | Noise: | <=40dB |
| Cooling: | Active cooling with fan | ||
| Protection: |
Input low-voltage&over-voltage protection Overheat protection Output empty-load protection Output short&reverse protection Output over-current&over-voltage protection Automatic shutdown when fully charged |
||
Common Output:
| Common Output | ||||||
| Model | Nominal Voltage | Lead Acid | LiFePO4 | NCM/NCA | Max Charge Current | Dimensions |
|
E22 |
12V | 14.7V | 14.6V | 16.8V | 40A |
Size:282*168*95mm |
| 24V | 29.4V | 29.2V | 29.4V | 40A | ||
| 36V | 44.1V | 43.8V | 42V | 40A | ||
| 48V | 58.8V | 58.4V | 58.8V | 35A | ||
| 60V | 73.5V | 73V | 67.2V | 30A | ||
| 72V | 88.2V | 87.6V | 84V | 25A | ||
| 84V | 102.9V | 100.8V | 20A | |||
| 96V | 117.6V |
18A |
||||
