Product Details:
|
| Material: | Aluminium | Product Name: | 900w Battery Charger |
|---|---|---|---|
| AC Input: | 85V-365V/40-70Hz | Waterproof: | IPx4 |
| Output Power: | 900W | Size: | 205*105*68mm |
| High Light: | 29.2V 24v lithium ion battery charger,24v lithium ion battery charger 44.1V,43.8V 12v 30a battery charger |
||
Lithium Battery Charger 44.1V 43.8V 42V 36V 20A 29.4V 29.2V 24V 16.8V 14.7V 14.6V 12V 30A Battery Charger
Specifications:
| Model: | OK-CH-900 | Max Power: | 900W |
| Shell: | Aluminium profile | Size: | 205*105*68mm |
| AC Input: | 85V-265V/40-70Hz | Waterproof: | IPx4 |
| Max Efficiency: | >90% | Operating Temperature: | -30 to 65℃ |
| Storage Temperature: | -40 to 95℃ | Noise: | <40dB |
| Cooling: | Active cooling with fan,nature cooling | ||
| Protection: |
Input low-voltage&over-voltage protection Overheat protection Output empty-load protection Output short&reverse protection Output over-current&over-voltage protection Automatic shutdown when fully charged |
||
| Common Output(Examples for lead acid battery @220Vac) | |||
| Example | Rated Output Voltage | Max Output Voltage | Max Output Current |
| 12V/30A | 12V | 17V | 30A |
| 24V30A | 24V | 34V | 30A |
| 36V20A | 36V | 51V | 20A |
| 48V18A | 48V | 68V | 18A |
| 60V15A | 60V | 85V | 15A |
| 72V12A | 72V | 102V | 12A |
| 84V10A | 84V | 118V | 10A |
| 96V8A | 96V | 135V | 8A |
Customization:
AC plug: US/EU/AU/UK/.....
AC wire: 1m/1.2m/1.5m/2m/.....
DC connector: Bare wire end/Anderson/REMA/EZGO/YAMAHA/YEEDA/SC/OT/Alligator clip/....
DC wire:1m/1.5m/2m/3m/.....
We have Computer Controlled Power Supply Burn-in Testing System to test each charger for 5 hours to make sure all of them can work well.
