Product Details:
|
| Material: | Aluminium | Product Name: | 300w Battery Charger |
|---|---|---|---|
| Waterproof: | IPx4 | AC Input: | 85V-365V/40-70Hz |
| Output Power: | 300W | Size: | 188*90*53mm |
| High Light: | 300W charge lithium battery with lead acid charger,charge lithium battery with lead acid charger 96V,84V lithium and lead acid battery charger |
||
Lithium Battery Charger 300W LiFePO4 Lead Acid 96V 84V 72V 3A 60V 4A 48V 5A 36V 7A 24V 10A 12V 15A Battery Charger
Specifications:
| Model: | OK-CH-300 | Max Power: | 300W |
| Shell: | Aluminium profile | Size: | 188*90*53mm |
| AC Input: | 85V-265V/40-70Hz | Waterproof: | IPx4 |
| Max Efficiency: | >=89% | Operating Temperature: | -30 to 65℃ |
| Storage Temperature: | -40 to 95℃ | Noise: | <=40dB |
| Cooling: | Active cooling with fan | ||
| Protection: |
Input low-voltage&over-voltage protection Overheat protection Output empty-load protection Output short&reverse protection Output over-current&over-voltage protection Automatic shutdown when fully charged |
||
Common Output:
| Common Output | ||||||
| Model | Nominal Voltage | Lead Acid | LiFePO4 | NCM/NCA | Max Charge Current | Dimensions |
|
E3 |
12V | 14.7V | 14.6V | 16.8V | 15A |
Size:188*90*53mm |
| 24V | 29.4V | 29.2V | 29.4V | 10A | ||
| 36V | 44.1V | 43.8V | 42V | 7A | ||
| 48V | 58.8V | 58.4V | 58.8V | 5A | ||
| 60V | 73.5V | 73V | 67.2V | 5A | ||
| 72V | 88.2V | 87.6V | 84V | 3A | ||
| 84V | 102.9V | / | 100.8V | 3A | ||
| 96V | 117.6V | / | 117.6V | 3A | ||
LED Indicator:
For Lead Acid Battery:
1,Battery power <80%,the red light blinks.
2,80% <Battert power<90%,the yellow light blinks.
3,90%<Battery Power<100%,the green light blinks.
4,Battery power=100%,the green light is always on.
Aging:
