Product Details:
|
| Battery Material: | LFP | Model Number: | OK-CS-HV48100 |
|---|---|---|---|
| Nominal Voltage: | 51.2V (16 Cells) 384V Customized | Capacity: | 50kwh 100kwh 200kwh |
| Inverter Compatible: | Victron, Deye,Growatt Etc. | Cycle Life: | ≥3000 (1C @ 25℃ 100%DOD) |
| High Light: | CE Commercial Solar Battery Storage Systems 96V 51.2V,CE 51.2V Commercial Solar Battery Storage Systems 96V,CE 51.2V Commercial Solar Battery Storage System 96V |
||
Commercial Solar Battery Storage Systems LifePo4 96V 192V 384V 100Ah High Voltage Lithium Ion Battery storage
Product Description:
1.Safety/Reliable LFP chemistry;
2.Long service life;
3.Intelligent BMS built-in;
4.Compact size for easy installation;
5.Diverse model options and Expansion;
6.Many inverters compatible;
Specification:
| Battery type | LFP-Lithium iron phosphate-LiFePO4 |
| Nominal Voltage | 51.2V (16 cells) 384V customized |
| Rated Capacity | 100Ah |
| Rated Energy | 5 0KWh 100KWh 200KWh |
| Size | customized |
| Weight | customized |
| Charge Limit voltage | 57.6 V |
| Discharge Limit voltage | 43.2 V |
| Standard charge current | 20A |
| Max charge current | 80A |
| Standard Discharge current | 50A |
| Max Discharge current | 100A |
| Operation Temperature | 0 – 45 ℃ |
| BMS function | Battery management system (BMS)Built in, voltage and current protection for overcharge and discharge , support CAN/RS485/RS232 communication, History records. |
| Inverter compatible | Victron, Deye,Growatt etc. |
