Product Details:
Place of Origin: China
Brand Name: SUNFiD
Certification: CE,IEC,CQC,CNAS
Model Number: SFD-PV400M2-HP108F
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: Negotiable Price
Packaging Details: CARTON WITH WOODEN PALLET
Delivery Time: 10-30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5MW PER MONTH

Energy Storage System Customized Solar Panels 400W Monocrystalline Bifacial PERC 108 Cells

Description
Product Name: 400 Bifacial Solar Panels Material: Solar Cells+ Duable Glass
Max. Power: 400W Panel Dimensions: 1722×1134×30mm
Open-Circuit Voltage(Voc): 37.94V Junction Box: IP68 Rated
High Light:

400W Monocrystalline Solar Panel

,

108 Cells Customized Solar Panels

,

Energy Storage System Bifacial Solar Panels

Residential Energy Storage System Solar Panels 400W Monocrystalline Bifacial PERC 108Cells



400W Bifacial Glass Solar Panels Description:

1. The appearance of  components are elegant and simple, perfectly combined with the architectural style.
2. 10BB is combined with 182*91mm cell technology, which has more reliable performance, effectively reduces the power loss caused and achieves higher power output.

3. Double-sided absorption of solar radiation, the double-sided ratio is as high as 70%, which greatly improves the equivalent power of the module



Solar Panel Application:

Highly used in Gound power plants, Commercial / Industrial roof-tops, Residential roof-tops, Agricultral PV Project



400W Bifacial Glass PanelsPamameters:

ELECTRICAL SPECIFICATION (STC)
Max-power 400
Power Tolerance 0~+6W
Voltage at Pmax (Vmp) 30.8
Current at Pmax (Imp) 12.99
Open-Circuit Voltage(Voc) 37.94
Short-Circuit Current (lsc) 13.8
Module Efficiency(%) 20.48
No. of Bypass Diodes(pcs.) 3
Max. Series Fuse(A) 25A
Operating Temperature - 45~+85 ℃
Max Static Load 5400P
Max-System Voltage(VDC) 1500 VDC(IEC)
Fire Rating Class C
STC: Irradiancec 1000W/m2, Cell Temperature 25 ℃,Air Mass 1.5



FAQ:

Q: Are you a manufacturer of trader?
A: We are a manufacturer of solar system kits, such as energy storage battery, solar inverters and solar panels.

Q: Can i use an AGM type battery for these 440W Solar Panels?
A: Yes. You can set the battery type to AGM according to the instructions. The battery types compatible with are as follows
SLA(lead-acid battery), GEL Battery, AGM Battery, Lithium-ion Battery, Ternary Lithium Battery



Q: How do you assure good quality products?
A: Quality is priority,100% 24 hours aging quality test before packing to assure reliable quality.
