Product Details:
Place of Origin: China
Brand Name: SUNFiD
Certification: CE,FCC,MSDS,ROHS,UN38.3
Model Number: CES-1KKD1KA
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: Negotiable Price
Packaging Details: Customized Contianers
Delivery Time: 10-30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2containers per month

1MW Container Energy Storage Battery ESS Commercial Battery Storage Integrated System

Description
Item: 1.29MW Energy Storage Container Rated Power: 1290KW
Battery Voltage: 672~864V BMS: 3 Grades
Size: 10Feet(2991*2896*2438mm) AC Voltage: 400VAC Or Customized 1000VAC

1MW Container Energy Storage Battery ESS Commercial Battery Storage Integrated System



1MW Energy Storage System is highly integrated with lithium battery, battery management system, PCS, grounding system, power distribution system, temperature control system and fire protection system. The AC voltage is 400VAC, which can provide peak and valley filling, grid frequency adjustment, power expansion and backup. Power supply and other functional services to help customers reduce electricity costs to the greatest extent. Recommended for industrial and commercial users, optical storage and charging support, super fast charging station support and other scenarios

ESS Container Storage Energy System Features

  • Standard 10feet container design, compact design, suitable for small user scenarios
  • 280Ah PACK+PACK level targeted fire + fan speed regulation
  • DC 1000V, 20 years of normal use
  • Main control cabinet, integrating DC confluence, power distribution, communication and control

1.29MW Outdoor Energy Storage System Parameters:

Item Name Container Energy Storage Battery1290
Cell Type LFP-3.2V-280Ah
Rated Capacity (KWh) 1290.24
Battery Voltage Range (V) 672-864
System Parameters
BMS 3 Grade
Size(mm) 2991*2896*2438 (10 Feet)
Weight(KG) 14T
IP Grade IP54
Operation Temperature Range -30°C ~ +50°C
Aux. Power Parameters 14KW-380V/50HZ
Fire Protection Aerosol S/ Heptafluoropropane / Perfluorohexanone
Installation Mode Outdoor Installation
System Communication Protocol Modbus TCP
